19
Figure 8: Vertical Vent Termination
Extend Vent Piping to maintain minimum vertical (“X”) and minimum horizontal (“Y”) distance of twelve (12) inches from roof sur-
face. Allow additional vertical (“X”) distance for expected snow accumulation.
