Burnham SERIES 2 - Page 35

35
Key
No.
Description
Boiler
Size
Part No. Qty.
3. Base Assembly Continued
3E Base Leg Assembly
Al l 61860 01 4
3E1 Base Leg
All 71860021 4
3E2 Nylon Glide
Al l 81860 06 4
3F Burner Access Panel
202 7186002 61 1
202X 7186 00361 1
203 7186003 61 1
204 7186004 61 1
205 7186005 61 1
206 7186006 61 1
207 7186007 61 1
208 7186008 61 1
209 7186009 61 1
210 7186010 61 1
3G
Cerafelt Sealing Strip,
1" x 2" x 10' (Section
Assembly to Base)
Al l 62060 02 1
3H Self-Tapping Screw,
¼" - 20 x ½"
202
thru
206
8086070 0 20
207
thru
210
8086070 0 21
3J
Self-Tapping Screw,
5/16" - 18 x 1-1/4"
All 80860717 4
3K
Flat Washer, 5/16",
USS
All
Common
Hardware
4
3L Lock Washer, 5/16"
Al l
Common
Hardware
4
3M Hex Nut, 5-16,
All
Common
Hardware
4
Key
No.
Description
Boiler
Size
Part No. Qty.
3. Base Assembly Continued
3C
Base Front Panel
Assembly
202 61 8600241 1
202X 61 8600341 1
203 61 8600341 1
204 61 8600441 1
205 61 8600541 1
206 61 8600641 1
207 61 8600741 1
208 61 8600841 1
209 61 8600941 1
210 61 8601041 1
3D
Burner Tray
(1" Main Burners)
202 718600205 1
202X 718600305 1
203 718600305 1
204 718600405 1
205 718600505 1
206 718600605 1
207 718600705 1
208 718600805 1
209 718600905 1
210 718601005 1
Burner Tray
(50 mm Main Burners)
203 7817038 1
204 7817048 1
205 7817058 1
206 7817068 1
207 7817078 1
208 7817088 1
209 7817098 1
210 7817108 1
Burner Tray
(40mm Main Burners)
202 71 8600206 1
202X 71806037 1
203 7180 6037 1
204 7180 6047 1
205 7180 6057 1
206 7180 6067 1
207 7180 6077 1
208 71 8600806 1
209 71 8600906 1
210 71 8601006 1
