Burnham SERIES 2 - Manifold and Main Burners (40 Mm Main Burners)

40
Figure 36a: Manifold and Main Burners
(40mm Main Burners)
Key
No.
Description Part No.
Quantity
202 202X 203 204 205 206 207 208 209 210
4. 40MM MAIN BURNERS ONLY
4A Main Burner 8236135 --- 1 1 2 3 4 5 6 7 8
Intermittent Ignition Only
4B
Main Burner with 48° Pilot B rac ket 8236143 1 --- --- --- --- --- --- --- --- - --
Main Burner with 41° Pilot Bracket 8236136 1 1 1 1 1 1 1 1 1
24-volt Continuous Ignition (Standing Pilot) Natural Gas Only
4B
Main Burner with 48° Pilot Bracket 8236143 1 1 1 1 1 1 --- --- --- ---
Main Burner with 41° Pilot Bracket 8236136 --- --- --- --- --- --- 1 1 1 1
24-volt Continuous Ignition (Standing Pilot) LP Gas Only
4B
Main Burner with 48° Pilot Bracket 8236143 1 1 --- --- --- --- --- --- --- ---
Main Burner with 41° Pilot Bracket 8236136 --- --- 1 1 1 1 1 1 1 1
