Burnham SERIES 2 - Page 43

43
Key
No.
Description Part No.
Quantity
202 202X 203 204 205 206 207 208 209 210
5. Pilot Burner and Gas Valve, 24-volt Continuous Ignition, LP/Propane (1 Inch and 40mm Main Burners Only)
5A
Pilot Burner, Robertshaw 7CL-6 8231703
1
*
1
*
--- --- --- --- --- --- --- ---
Pilot Burner, Honeywell Q327A1915 8236106
------11111111
Pilot Burner, Honeywell Q350A2279 8236105
1
**
1
**
--- --- --- --- --- --- --- ---
5B
Pilot Orifice, Robertshaw 27270-1 (.008")
Included
With 5A
1
*
1
*
--- --- --- --- --- --- --- ---
Pilot Orifice, Honeywell 388146KR (.014")
------11111111
Pilot Orifice, HoneywelL 390686-23 (.008")
1
**
1
**
--- --- --- --- --- --- ---
5C
Adptr, 1/4"OD x 1/4" NPT Included w/5A & 5E 8236109
2
*
2
*
--- --- --- --- --- --- --- ---
Adptr, 1/8"OD x 1/4" NPT Included w/5A & 5E 8236108
2
**
2
**
22222222
5D
Pilot Tubing, 1/8" OD x 30" LG 8236110
1
**
1
**
11111---------
Pilot Tubing, 1/8" OD x 40" LG 8236100
--- --- --- --- --- --- --- 1 1 1
5E
Gas Valve, Honeywell VR8200C3013 81660144
1
*
1
*
--- --- --- --- --- --- --- ---
Gas Valve, Honeywell VR8200C6040 81660243
1
**
1
**
1 1 1 1 --- --- --- ---
Gas Valve, Honeywell VR8300C4548 81660244
--- --- --- --- --- --- 1 1 1 1
5F
Thermocouple, 30", Robertshaw 42930 8231704
1
*
1
*
--- --- --- --- --- --- --- ---
Thermocouple, 30", Honeywell Q309A 8236024
1
**
1
**
11111111
5G
Pilot Tubing, 1/4" OD x 18" LG 8236048
1
*
1
*
--- --- --- --- --- --- --- ---
5L
Compression Coupling, 1/4" x 1/4" x90° 8236046
1
*
1
*
--- --- --- --- --- --- --- ---
5M
Pilot Tubing, 1/4" OD x 9" LG 8236047
1
*
1
*
--- --- --- --- --- --- --- ---
*1" Burner Only
** 40mm Burner Only
