33
Ref. Description Quantity
1 Grilling chamber 1
2 Thermal Baffle 1
3 Combustion chamber 1
4 Base cabinet (Ref. 49 – 63) 1
5 Heat conduction sheet 1
6 Grease removal sheet 1
7 Main stainless steel grid 1
8 Top stainless steel grid 1
9 Top stainless steel grid 1
10 Pellet chamber 1
11 Handle bracket grill chamber 2
12 Lid handle grill chamber 1
13 Lid grilling chamber 1
14 Hinge lid grilling chamber 2
15 Cap nut 2
16 Hinge Pin 2
17 RTD temperature sensor 1
18 Grilling grid bracket top 2
19 Chimney cover 1
20 Chimney 1
21 Chimney sealing 1
22 Serving board for front tray 1
23 Frame for front tray 1
24 Bottle opener 1
25 Left connection for front tray 1
26 Right connection for front tray 1
27 Bracket front tray left 1
28 Bracket front tray right 1
29 Grease collection basket 1
49 Lower hinge door 2
50 Door base cabinet left 1
51 Upper hinge door 2
52 Door base cabinet left 1
53 Magnet fixing pate 1
54 Cross strut 1
55 Magnet 4
56 Back panel base cabinet 1
57 Side panel base cabinet left 1
58 Door base cabinet right 1
59 Door handle base cabinet 2
60 Grip holder base cabinet 4
61 Rollers 4
62 Floor base cabinet 1
63 Base cabinet shelf 1
