BURNHARD Flint - Assembling the Pellet Smoker

36
ASSEMBLING THE PELLET SMOKER
ASSEMBLING THE BASE CABINET
Turn the lower panel around. Screw the
magnet mounting pate on the marked
position and insert magnets into the holes.
2
Pace the bottom panel with the inside fa-
cing down. Enter the rollers into the screw
holes and tighten with a screwdriver.
1
Attach both side panels to the
lower panel.
3
