35
Ref. Description Quantity
30 Lid pellet chamber 1
31 Pellet chamber funnel 1
32 Pellet chamber grate 1
33 Pellet chamber housing 1
34 Operating element 1
35 Floor cover pellet chamber 1
36 Motor 1
37 Spiral conveyor socket 1
38 Power cable 1
39 Pellet chamber seal 1
40 Power cord separator 1
41 Spiral conveyor 1
42 Ignition rod 1
43 Combustion chamber element 1
44 Combustion chamber housing 1
45 Combustion chamber seal 1
46 Pellet chamber/combustion chamber design 1
47 Fan 1
48 Cable suspension 1
ATTACHMENTS
