BURNiT PM 23kW - Messages and Alarms; Alarm Conditions and Display

35 - EN
Installer / Service Manual BURNiT Comfort PM/PM-B
After the pellet stove is with power supply cut off, depending of the mode canceled, on the screen
the following message displays:
Previous MODE
Duration of
time without power
NEW MODE
Switching ON
Meaningless
SWITCHNING OFF
IGNITION <T IGNITION
Loading with pellets
,
without reloading
<T
Loading with pellets
Loading with pellets,
with reloading
<T SWITCHNING OFF
Wait for fire/burning <T Wait for fire/burning
Working mode
<T
Working mode
Cleaning of the burner
<T
Cleaning of the burner
SWITCHNING OFF <T SWITCHNING OFF
In the cases that the period of the time without power supply is bigger than Т, the pellet stove
switches OFF.
9. Messages/Alarms
If an anomaly occurs in working mode of the pellet stove then a specific message/alarm is shown on
the screen.
MESSAGE
/
ALARM Type
DISPLAY ON THE SCREEN
Power supply failure
AL 1
Sensor exhaust gases malfunction
AL 2
Too high exhaust gases temperature AL 3
Fan malfunction
AL 4
Lack of flame/burning AL 5
Lack of pellets in the hopper AL 6
Active safety thermostat,
Active water thermostat, open door,
clogged chimney, low fan speed
AL 7
Malfunction of the water temperature sensor of the pellet stove AL 9
High water temperature in the pellet stove AL B
AFTER EACH MESSAGE/ALARM THE PELLET STOVE AUTOMATICALLY SWITCHES OFF
Message/alarm mode is reached by PR 11 and is canceled/ deactivated by pressing key P4.
