7 - EN
Installer / Service Manual BURNiT Comfort PM/PM-B
2.4. Mounting the controller of the pellet stove
Open the cover of the container for pellets situated on the top of the product.
Inside you will find the packed controller (2), together with a set of bolts M5 (3).
Unpack the controller (2), put the cable (4) through the hole of the panel (see the scheme above)
and connect it to the card slot. Use bolts М5 for mounting the controller (2) to the body of the pellet
stove. Pay attention not to damage the cable when connecting to the controller.
