GB
102
Settings
• After conclusion of the "testing phase", set the potentiometer to the desired switch-on
delay for Output 2 (s. Chap. 5.5).
The settings of all three potentiometers are then again active.
6.2 Master/Slave Mode (see Fig. 2)
Master/Slave Mode allows larger areas to be monitored.
The brightness in the room is assessed exclusively by the Master. The Slaves must report
movements detected to the Master. The Master, alone, switches the lighting and/or HAV
system on and off.
Device Combinations
Master/Slave mode is possible when the Presence Detector is combined with the following
devices:
Master
The Presence Detector in conjunction with FM Insert 6401U-102 or 6804U or 6590U-103
or 6550U-101.
Slave
The Presence Detector in conjunction with FM Insert 6805U.
