GB
85
Fig. 9/Fig. 10
Device representation (top view)
1. Sensor for infrared reception (red)
2. Sensor for measuring brightness
(transparent)
3. Lens system consisting of four
elements
Device representation (back)
4. Three potentiometers for setting
manually
5. Clips
6. Terminal pins
4
5
6
1
2
3
