Product Description | 3
0870524638_RA_Aqua_A0003_IMS_en
5 / 12
3
Product Description
IN
IF
GB1
GB2
WS
OUT
TS
IN
IF
GB
WS
OUT
TS
RA 0165-0305 D Aqua
RA 0400-0630 C Aqua
IN
IF
GB1
WS1
OUT1
GB2
WS2
OUT2
RA 1000-1600 B Aqua
CD2
CD1
CD
CD
IN
Suction connection
IF
Inlet filter
OUT
Discharge connection
CD
Condensate drain
TS
Temperature switch
WS
Water separator
NOTE
Illustrations
In this instruction manual the illustrations may differ from the machine appearance.
