Installation | 5
Instruction Manual TYR WT 0100-0730 CP CV_EN_en 13 | 44
5.3 Connecting Lines / Pipes
● Remove all protective covers before installation.
● Make sure that the connection lines cause no stress on the connections of the machine. There-
fore, we recommend installing flexible joints on the suction and discharge connections.
● Make sure that the line size of the connection lines over the entire length is at least as large as
the connections of the machine.
In case of long connection lines, it is advisable to use larger line sizes in order to avoid a loss of effi-
ciency. Seek advice from your Busch representative.
WARNING
The pipe installation must be made from conducting material in order to avoid build up of
static electricity.
Pipe installation on the exhaust side must be made from heat resistant material.
Risk of severe injury!
Risk of damage to the machine!
5.3.1 Suction Connection
WARNING
Unprotected suction connection.
Risk of severe injury!
● Do not put hand or fingers in the suction connection.
NOTICE
Ingress of foreign objects or liquids.
Risk of damage to the machine!
If the inlet gas contains dust or other foreign solid particles:
● Install a suitable filter (5micron or less) upstream from the machine.
Connection size(s):
– Ø 114 mm for WT 0100 CV/CP and WT 0150 CV/CP
– Ø 159 mm for WT 0280 CV/CP and WT 0390 CV/CP
– Ø 219 mm for WT 0600 CV/CP and WT 0730 CV/CP
Depending on the specific configuration ordered, other connection dimensions may apply.
● Make sure that the connection lines cause no stress on the connections of the machine. There-
fore, we recommend installing flexible joints on the suction and discharge connections.
