BWT EASY DOSE - Technical specifications

TRAITEMENT DE L’EAU
26
2023/04 - Indice de révision : A - Code : 29600
BWT EasyDose_ORP for electrolyser
BWT EasyDose_Flocculant
11.1 Technical specifications
Specifications
EasyDose
pH
EasyDose
ORP
EasyDose
ORP_Electrolyser
EasyDose
Floc
Measurement range
3.2 ÷ 8.2 pH (*
1
)
400÷999 mV (*
1
)
400÷999 mV (*
1
)
---
Measurement accuracy
± 0.02 pH
± 2 mV
± 2 mV
---
Instrument resolution
± 0.1 pH
± 10 mV
± 10 mV
---
Pump flow rate
1.5 l/h
1.5 l/h
No pump
15 to 150 ml/h
Power supply
220 - 240 Vac 50/60 Hz
100 ÷ 240 Vac
50/60 Hz
Electricity consumed
9 Watt
Dosing method
ON-OFF
with adjustment of the setpoint
Electrolyser ON/OFF,
with adjustment of
the setpoint
Adjustable injected
volume
Pumps status
Standby – Active
No pump
Standby– Active
Display screen
4 digits with 7 segments
Probe calibration
Automatic
No probe
Max. back pressure
1.5 bar
1.5 bar
No pump
1.5 bar
Weight
0,95 kg
Dim. (Width–Height–Depth)
89 x 138 x 118 mm (3.85" x 5.3" x 4.6")
Schuko plug (Female)
None
None
230 Vac 8A
None
(*
1
) The pump features galvanic insulation and insulation of the measurement signal.
A: 1 x PSS3
probe housing
(1/2” GAS union)
B: Saddle clamp,
50 mm, tapped
½’’
C: Mounting kit
(screw =6 mm
D: ORP probe
E: Buffer solution
465 mv
A: 1 x Crystal
PVC suction
tubing 4 mm x 6
mm (2 m)
B: 1 x
Polyethylene
return tubing (2
m)
C:1 x injection
valve, FPM
(3/8” unions )
D: 2 x saddle
clamps, 50 mm,
tapped ½’’
E: Reducer for
injection valve
(1/2” M to 3/8” F
F: Tank floor
suction strainer
(PP foot)
G: Mounting kit
(screw =6 mm))
I: coupling nut
to connect the
tubing to the
pumps
