13. Electrical connections
6. ON-OFF switch
7. Power cable
8. BNC connector for pH or ORP probe
(NB : Floc version, no probe)
9. Suction tube union
10. Return tube union
14. Parameter setting and operation
14.1 BWT Easy Dose flocculant
Switch positions
1 : Normal dosing position
The pump runs at the selected speed when the device is powered on.
The pump speed can be set at between 10 and 100% of its maximum speed.
To set the pump speed, press the key to scroll through the values until the required setting is
displayed, then release it. 3 seconds later, the displayed value is saved to memory, and “mem” is displayed
on screen.
0: The pump is stopped.
Mounting the probe on the
BNC connector
4
5
1
2
3
