BWT EASY DOSE - Mounting the suction kit; Mounting the pH and;or ORP probes

TRAITEMENT DE L’EAU
32
2023/04 - Indice de révision : A - Code : 29600
12.4.4 Mounting the suction kit
12.4.5 Mounting the pH and/ or ORP probes
WARNING
Probes are delicate. They must be regularly maintained and calibrated using the buffer solutions
provided with the device. In the event of a fault, there is a risk that excess chemical could be
injected and that water quality could be degraded.
WARNING
If the probes are mounted on a by-pass loop, make sure that the shut off valves are open
while the device is in operation.
Poser le clapet lesté de fond de
bac et ajuster la profondeur.
Serrer l’écrou sur la
pompe doseuse.
PVC tubing
(transparent)
Suction valve
Tighten the nut onto the
dosing pump.
Place the weighted valve in the
bottom of the tank and adjust the
depth.
Remove the probe from its
protective sleeve and undo the
probe housing nut.
Slide the nut onto the probe,
making sure that the seal is in
place underneath, then insert the
probe.
Hand tighten the probe housing
nut. The probe is ready!
