BWT Euromat 2 - Technical Specifications

GB
ind.1 du 16/10/2012 8 EUROMAT 2 P0011049
manufacture according to the rules of the art in use) but
does not come into categories I to IV and hence is not
concerned by EC labelling relating to equipment under
pressure.
Technical data:
Supply voltage : 230 volts 50/60 Hz
Power consumption : 6 watts in operation
: 25 W in regeneration
Maximum pressure : 6 bars static
Minimum pressure : 1.5 bar dynamic
Minimum regeneration output : 0,5 m³/h
Water temperature : min. 1°C
: max. 30°C
Ambient temperature : min. 5°C
: max. 40°C
Nominal output
in m3/h
1.0
2.0
2.5
Utilisation output
in m3/h minimum
0.35
0.35
0.35
Weight of salt per
regeneration in kg
1.2
2.9
3.8
Exchange capacity
in °dH.m3 standard
25
50
75
Exchange capacity
in °f.m3 standard
45
89
134
Volume of resin
in litres
10
16
22
Characteristics
25
50
75
