BWT PRO A 22 - Page 35

2021/03 - Indice de révision : B Code : 29740TRAITEMENT DE L'EAU
35/88
Description Qty Comments
Sensorhousing,
3 positions
1
The housing holds the water
temperature sensor, and can
accommodate the pH and Redox
sensorsiftheseoptionswereadded.
Install it on a by-pass loop between
the ltration pump and the lter (see
thehydraulicdiagrampara4.1)
Int.diam. = 50 /
Ext.diam. = 63
2holeswithcapsonone
side,1ontheotherside
OptionalpHkit 1
Thiskitcomprises:
• Peristaltic pump, 1.5 l/h for pH
reducedrand1.5mcable
• pH sensor
• 1sensorthermowell
• 1cablegland
• 1saddleclamp,solvent
• 3 buffersolutions: distilled water,
pH=7,pH=10
• 1 reader to be mounted on the
motherboardinthecontrolpanel
OptionalRedoxkit 1
Thiskitcomprises:
• Redox sensor
• 1sensorthermowell
• 1cablegland
• 1saddleclamp,solvent
• 1neutralsolution,
• 1 465 mV solution
• 1 reader to be mounted on the
motherboard in the control panel
(sameforpHandRedox)
OptionalWi-Fikit 1
• 10mcable
• Wi-Fi module
OptionalFlow-switchkit
installed as standard on
thePROLS300model,
availableasanoptionfor
othermodels
1
• 1saddleclamp,3/4"
• 1ow-switchwith1.5mcable
