BWT PRO A 22 - Variable Speed Pump Connections

2021/03 - Indice de révision : B Code : 29740TRAITEMENT DE L'EAU
41/88
Contacteur
de pompe
Pump
contactor
Donotconnectthedevicetothemainsuntilalltheconnectionshavebeenmadeinthecontrolpaneland
ithasbeenclosed.
**slavingtheltrationpump:
Caution:thedryslavingcontactofthexedspeedltrationpumpacceptssinglephasecurrentsupto12A
max.Intheeventthatthecurrentisgreaterthanthisvalue,orthata3-phasepumpisinstalled,thiscontact
cannotbeusedforthepumppowersupply,butshouldbeusedtosupplythecoilofacontactorlocated
upstreamfromthepumppowersupply.
ByconnectingtheltrationpumptotheChlorinegeneratorcontrolpanel,youcanprogrammedailyrun
windowsfortheltrationpumpinsteadofusingthetimerinthepumpelectricalpanel.
NoteBene:TheChlorinegeneratorcontrolpaneldoesnotforcethepumponoutsideprogrammedwindows
inAUTOmode,evenifthereisapHreducerofChlorinedemand(pHhigherthantherecommendedset
pointand/orRedoxlowerthantherecommendedsetpoint).
***Avariable speedltration pump iswired inusingtwo terminals:thatspecic tothe variablespeed
pumpalreadymentioned(seegure),andthatofthexedspeedpumptowhichthefollowingconnections
shouldbemade:
• CreateashuntbetweenterminalsCandD
• Connectthelivewiretooneofthetwoterminals,CorD.
