2. No lighting & sufficient SOC. MINI ES provides electricity to electric appliances.
PV inverter
CT2
Grid
MINI ES
Indoor/
outdoor
Indoor/
outdoor
Power Line
Signal Line
Load L&N&PE
Combiner
box
CT1
Load Distributor
Single-phase
electric appliance
figure7. Power flow diagram
Indoor/outdoor
Grid
