18
6 ONU LAN Configuration
6.1 LAN IP Address Configuration
1Login ONU WEB, select Internet -> DHCP Server -> IPv4 DHCP Server, and then
there are some parameters for us to configure as follows:
IP address Set local management IP address of ONU. The default IP address is
192.168.101.1
Subnet maskSet the mask of local management IP address of ONU
Disable DHCP Server/Enable DHCP Server Enable or disable ONU DHCP Server
function.
Start IP address / End IP addressConfigure the IP address interval that allocated to the
terminal. The address interval must be on the same
network segment as the management IP address of
the ONU.
DNS1/DNS2/DNS3Configure DNS address that allocated to the terminal. By default,
192.168.101.1 of DNS agent address is used to default DNS
address. We can design this according to network plan.
Edit DHCP address rangeBy default, the ONU will allocate 10 IP addresses for every
kinds of terminal. If it is not enough, we can edit DHCP
address range to increase the designed address range.
