5.2 Configure Bridge WAN Connection for Internet
1Login ONU WEB, select Internet -> Internet Config -> Internet Config, and then there
are some parameter for us to configure as follows:
WAN Connection nameSelect ‘Add WAN Connection’
ModeSelect ‘Bridge
Connection Mode Select ‘Ipv4’; If there is Ipv6 in the network, we can select
‘Ipv4/Ipv6’.
NAT Don’t check ‘NAT’ featureNAT is mainly used for address translation function
of local network and external network. HGU ONU doesn’t deal with the packets
from the teminal, so we needn’t enable the NAT function.
Enable VlanWe can set this option according to your network plan. If there is vlan in
the network for Internet, we have to check ‘Enable VLAN’ option. If not,
we needn’t check this option, which will be VLAN transparent mode.
Vlan IDConfigure this option according to our network plan.
MTUThe default is 1500we have to change to lower MTU, such as 1400, if we can
ping the DNS but not access the website via WEB broswer.
Service Mode Select Other or ‘Internet’Normally, select ‘Internet’ for Internet or
flow testing; Select ‘Other for IPTV service.
LAN DHCP DisableCheck this optionNormally, Terminal , connected to the HGU
ONU, will get an IP address from the upper DHCP server.
Therefore, we need check this option to avoid the terminal get
an IP from the ONU.
Bind port Bundel the physical ports (Lan port 1-4 and wireless) with Bridge WAN
connection.
Note: By default, all LAN ports and WIFI data are not bound by this WAN connection (a
LAN and WIFI SSID can only be bound to a WAN conection at the same time).
