Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055)
Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
27
6.2 Configure Process
6.3 Configure OLT Service
6.3.1 Configfure OLT Globle Vlan
In config mode,we can use OLT(config)# show vlan all to show the created vlan.
If the created vlan cant meet the need,we can use command OLT(config)# vlan vlan-list to create
new vlan,According to the data plan, we create vlan100,vlan200,vlan300 firstly:
OLT(config)# vlan 100
OLT(config)# vlan 200
OLT(config)# vlan 300
6.3.2 Configure OLT GE Port Service Vlan
We can config GE port vlan mode as access,hybrid and trunk,according to our network plan
configure different mode, configure way of three mode as follows.
Bridge ONU Port Config
LAN 1 VLAN 100
LAN 2 VLAN 200
LAN 3 VLAN 300 ---connect to VOIP phone
Gateway ONT Port Config
LAN1 VLAN 100
LAN2 VLAN 200
POTS1 VLAN 300
End
Create OLT globle vlan
Configure OLT GE port vlan
Configure OLT PON port vlan
Create DBA profile
Save OLT configuration
Start
Create ont srvprofile
Register ONU,and bind
lineprofile and srvprofile
Create ont lineprofile
