Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055)
Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
Note
The command line described in the document is case sensitive in OLT.
If we meet a command that cannot be inputed or is prompted for error,we can input “?” to
see the latter command format.
Input incomplete commands can be completed by pressing the “Tab” key.
FD1204S、FD1208S、FD1216S are Pizza-Box OLT，only have one card，so,if we want to enter
PON mode,need input interface epon 0/0
FD8000-L116 is Plug-in card OLT,has four PON card,so the comamnd for entering PON mode
is OLT(config)# interface epon 0/<SlotID> ,SlotID is Slot Number,range is 1-4，for example,the
command for entering slot 1 is OLT(config)# interface epon 0/1
2 OLT Login Manage
2.1 OLT Login Manage Explanation
FD1204S、FD1208S、FD1216S support CLI,EMS and WEB management;CLI manege type divided
into telnet remote manage and console local manage, please check #2.2 and #2.3 chapter to see
concrete operations;please check EMS user manual to see EMS manage way;please check #4 to
see WEB manage way.
2.2 OLT Login By Console
First,find console port on OLT front surface,which is a RJ45 port.if want to login OLT by Console
port,we need do prepare as follows:
Need RJ-45-to-DB-9 serial line
Connect PC to OLT concole port,find COM number in “computer management”
Software for logining OLT by console port(Putty,SecureCRT)
