7
19
16
15
14
13
12
10
9
11
17
20
21
9 Ribbon deection roller
10 Printhead retainer with printhead
11 Guides
12 Allen key
13 Printhead locking lever
14 Print roller
15 Guide roller
16 Label sensor
17 Knob for guide adjustment
19 Detent pin
20 Pressing roller system
21 Pinch roller
Fig. 3 Print mechanics A4+T
22
23
24
25
26
27
28
29
22 Power switch
23 Power connection jack
24 Slot for PC Card Type II
25 Slot for CompactFlash memory card
26 Ethernet 10/100 Base-T
27 2 USB master ports for keyboard,
scanner or service key
28 USB high-speed slave port
29 Serial RS-232 C port
Fig. 4 Connections
2 Installation
