40 cab Produkttechnik GmbH & Co KG

6. Control Panel

Fig. 6c Navigator Pad in the Offline Menu

After switching from the "Online" mode into the Offline Menu the function of the

keys are changed. Now the keys of the Navigator Pad have the function of

cursor keys.

Key Function

- Move up in the menu

- Increase numeric values

- Move down in the menu

- Decrease numeric values

- Switch to a secondary menu

- Move the cursor to the right during numeric settings

- Finish a setting with confirmation of the selected settings

- Start of a selected test or service function

- Return from a secondary menu

- Move the cursor to the left during numeric settings

- Finish a setting with rejecting the selected settings

- At the start of the menu, return to the system mode

"Online"
