26 cab Produkttechnik GmbH & Co KG
1
2
3
4
5
6
7
8
9
10
11
12
13
Fig. 4c Print mechanism R-Versions with printhead open
1 - Printhead locking screw
2 - Ribbon shield
3 - Label edge sensor
4 - Media feed roller
5 - Rewind guide plate
6 - Printhead support
7 - Screw to adjust the printhead support
8 - Printhead lever
9 - Screw to adjust the ribbon shield
10 - Thermal printhead
11 - Media guide
12 - Swing (A3: Guide axle)
13 - Allen Key
4. Printer Component Location
