FPGA: Rev.3
Fig. 9e Short status 5
The fifth line displays the revision number of the FPGA.
TPH: 300 dpi
Fig. 9f Short status 6
The resolution of the installed printhead is displayed on the sixth line.
Slot: -
Fig. 9i Short status 9
If the printer is equipped with the optional interface (RS-422/485, ethernet,
USB), it is displayed on the ninth line.
Card: 8 MByte
Fig. 9k Short status 10
If you are using a memory card, the capacity of the memory card is
displayed on the tenth line.
5. To leave the "Short status" display and return to the "Test" menu, press the
key.
TT: 64.44m
Fig. 9g Short status 7
The seventh line displays the length of material printed in thermal transfer
mode in realtime.
TH: 44.65m
Fig. 9h Short status 8
The eighth line displays the length of material printed in direct thermal mode
in realtime.
9. Test Options
To Next Page
