CAB eos 4 User Manual

16
17
4 Conguration
4.1.5 Status Line
Select the parameters (widgets) to be displayed in Ready mode.
 Start Ofine menu.
 Select Setup > Status line.
 Activate the desired widgets.
i
Notice!
Because of the limited width of the display it is not possible to display all widgets simultaneously.
Widget Meaning Default
Clock
Displays the current time.
On
Date sheet
Displays the current calendar day.
On
Date/time
digital
Digital display of current date and time
Off
Temperature
Displays the current printhead temperature.
Off
Ribbon supply
Displays the current ribbon supply in the form of a horizontal bar.
Off
Cutter
Displays a cutter connected
On
Ethernet Status
Displays the Ethernet status
Off
WLAN
Displays the WLAN status
- grey symbol if WLAN adapter is installed
- black symbol if WLAN adapter is connected to an Access Point
Off
Bluetooth
Displays the Bluetooth status
- grey symbol if Bluetooth adapter is installed
- black symbol if Bluetooth connection is active (paired, serial port open)
Off
Data transfer
Displays the current data transfer in the form of a falling drop.
On
Table 7 Parameters of the menu Setup > Status line
4.1.6
Security
By activating a PIN, the Setup menu, certain storage device functions and the rmware update can be protected
from unauthorized access.
The protected menu items are then only accessible after the PIN is entered.
 Start Ofine menu.
 Select Setup > Security.
Parameter Meaning Default
Security
Status of the PIN activation
Off
PIN
Setting of the PIN
0000
Table 8 Parameters of the menu Setup > Security
