11
2 Installation
2.3 Connecting the Device
2.3.1 Connecting to the Power Supply
The printer is equipped with a wide area power unit. The device can be operated with a supply voltage of
230 V~/50 Hz or 115 V~/60 Hz without adjustment.
1. Check that the device is switched off.
2. Plug the power cable into the power connection socket (25 / Figure 6).
3. Plug the power cable into a grounded socket.
2.3.2 Connecting to a Computer or Computer Network
Attention!
Inadequate or no grounding can cause malfunctions during operations.
Ensure that all computers and cables connected to the printer are grounded.
Connect the printer to a computer or network by a suitable cable.
FordetailsofthecongurationoftheotherinterfacesCongurationManual.
2.4 Switching on the Device
When all connections have been made:
Switch the printer on at the power switch (24 / Figure 6).
The printer performs a system test, and then shows the system status Ready on the display (21 / Figure 5).
