Series 90 Setup Manual Page 23
High-voltage Cable Assemblies
Cablescan
Part No.
Description First End
Connector
Second End
Connector
5211037 32-conductor High Voltage Cable 5211036
(no connector)
5211038 96-conductor High Voltage Cable 5211037 (x3)
(see ITT table)
Components for 5211036 Connector Kit
Cablescan
Part No.
Description
ITW
Part No.
5211036 32-pin DIN male connector 100-932-124
- Strain Relief 100-000-071
- Housing 100-000-064
Cablescan-to-ITT Cannon Part Number Conversion
Cablescan
Part No.
Description
ITT Cannon
Part No.
Cable End Connector Components
5211061 96-pin ZIF connector, plug DL2-96P
- 96-pin ZIF connector shell kit DL2-J/S
- 96-pin ZIF connector handle 2040016-000
- Contacts for ZIF connectors 030-2410-001
Panel-mount Connector Components
Mount on Harness Board/Fixture
5211060 96-pin ZIF connector kit DL2-96R
Kit contains 100 contacts 030-2410-001
High Voltage Cables and Components
