379 . . .
–
–
–
–
–
Section 5
The spare tire is attached to the
tire carrier underneath the vehicle.
1. Hoist Assembly
2. Hoist Shaft
7. Tire/Wheel Retainer
8. Spare Tire/Flat Tire (with valve
stem pointed down)
9. Hoist End of Extension Tool
10. Tire Lock
7
6
8
5
4
2
1
10
3
9
3. Hoist Shaft Access Cover/Hole
4. Jack Handle Extensions
5. Wheel Wrench
6. Hoist Cable
$10araEscaladeEXT Page 379 Wednesday, October 14, 2009 9:54 AM
