CAIRE Hi Flow Stroller - Specifications

Hi Flow Stroller Technical Service Manual • PN 14314465 Rev F
4
Hi Flow Stroller
Specifications (Nominal Values)
IV
HI FLOW STROLLER
Capacity
LOX lbs. (kg) 3.0 (1,36)
Liquid Liters 1,25
Gaseous Liters 1026
Hi Flow Selectable Flow Rates Off 0,5 1,0
2,0 2,5 3,0
4,0 6,0 8,0
10,0 12,0 15,0
Flow Rate Accuracy ± 0.1 liter per minute
or ±10% of flow setting,
whichever is greater
Normal Evaporation Rate lbs./day (kg/day) 1.2 (0,54)
Operating Pressure PSIG (Bar) 20 (1,4)
Primary Relief Valve Setting PSIG (Bar) 19.7 - 21.5 (1,35 - 1,48)
Secondary Relief Valve Setting PSIG (Bar) 27 - 33 (1,86 - 2,27)
Filling Time
Warm minutes:seconds 2:00
Cold minutes:seconds 1:00
Height in (cm) 13.5 (34,3)
Width in (cm) 7.25 (18.4)
Weight
Empty lbs. (kg) 5.1 (2,3)
Full lbs. (kg) 8 (3,6)
Fill Connector Types Male side mounted rotary coupling, female bottom mounted push-on coupling,
or female bottom mounted rotary coupling.
