8.10 Saddle
Checking that the saddle is fastened
Wanted state: The saddle is fastened and the saddle clamp groove aligns
with the subframe groove.
1. Check that the saddle clamp, see Fig. 27 (A) is properly fastened to the frame.
2. Perform a test drive to check for loose parts.
Adjusting the saddle height
1. Flip the saddle height lever backward.
2. Hold the nut located opposite the saddle height lever.
3. Rotate the saddle height lever counterclockwise until the saddle is loose.
4. Adjust the saddle height.
5. Ensure not to raise it above the seat pole mark “Min. insertion”.
6. Ensure the saddle clamp groove aligns with the subframe groove.
7. Hold the nut and rotate the saddle height lever clockwise.
8. Tighten the nut.
9. Flip the saddle height lever forward to lock it.
Fig. 27
A
B
C
47
A. Clamp
B. Adjustment screw
C. Angle and depth adjuster
