8.9 Lights
Checking that the headlight is fastened
Tool: Allen key 5mm, wrench 10mm.
1. Manually check if the headlight is firmly attached. If needed, fasten it;
continue below.
2. Carefully fold up the rubber protection enclosing the headlight.
3. Fix the nut while tightening the screw.
4. Perform a test drive to check for loose parts.
Checking that the taillight is fastened
Tool: Allen key 5mm, wrench 10mm.
1. Manually check if the taillight is firmly attached. If needed, fasten it;
continue below.
2. Carefully fold away the rubber protection (A) enclosing the taillight.
3. The nut is located under the rubber protection, and the screw is located
between the rear fender and the tire. Fix the nut while tightening the screw (B).
4. Perform a test drive to check for loose parts.
Fig. 26
Taillight attachment
46
A
B
