CalDigit TS4 - TS4 Port Diagram and Layout

5
TS4 Diagram
SD UHS-II / microSD UHS-II Card Reader Audio Combo Jack USB-A 3.2 Gen2 (10Gb/s)
USB-C 3.2 Gen2 (10Gb/s) USB-C 3.2 Gen2 (10Gb/s)
7.5W 20W
USB-A 3.2 Gen2 (10Gb/s) USB-C 3.2 Gen2 (10Gb/s)
7.5W 7.5W
DisplayPort 1.4PowerSecurity Slot
Downstream Devices
Thunderbolt 4 / USB4 (40Gb/ s)
15W
Upstream Host
