3 HARDWARE INSTALLATION
Before installing the S320 OCS for the first time, contact CALIENT Customer Service
at http://support.calient.net for the latest product software releases, and the latest
installation and configuration guides. In case you are unable to access the Internet,
every S320 OCS shipped comes loaded with the most current version of product
software available at the time of shipping, and a copy of the S320/160 OCS Quick
Start Guide.
3.1 Overview
Installing the S320 OCS includes the following tasks:
 Physically installing the switch in a rack
 Connecting the configuration interfaces (i.e., serial cables and Ethernet cables)
of the switch
 Connecting the power interfaces of the switch
 Booting up the switch
 Installing the fiber interfaces of the switch
3.1.1 General Requirements
Before the S320 OCS is installed, make sure the following requirements are met:
 7RU of rack space in a 19”, 23” or ETSI rack to house the switch
 A mounting shelf for use with two-post racks, or a support bracket set for use
with four-post racks
 Power accessible to the switch
 Input and output optical fiber cables with LC-UPC connectors, accessible at the
installed switch (i.e., in the rack)
 Computer resources providing VT-100 terminal emulation and a serial interface
accessible at the installed switch (i.e., in the rack)
