Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
Installation Manual
PPT8/12/16/22LX/LY SLIMLINE
SD638150 ISSUE 11
®
PPT8 WATER IN/OUT 1½" or 50mm FEMALE CONDENSATE ¾" DOMESTIC WASTE
WATER IN
WATER OUT
204
510.50364.25
70
480
97
532
AIR ON
AIR OFF
470
854
395
528
320.50
725
1237
1264
MAINS IN
CONDENSATE
165.50
46
457 490
518.50
594
THERMOSTAT
10.0 Installation Drawings
