System Hardware 25
Table 5: Force 4600C environmental specifications
Category Specification
Temperature -30°C to 55°C (-22°F to 131°F)
Wind loading 200 km/hour (124 mph)
Environmental IPx0
Heater
At start-up, if the Force 4600C module temperature is at or below 32°F (0°C), an internal heater is
activated to ensure that the device can successfully begin operation. The unit’s heater is only activated
when the unit is powered on and will not apply heat to the device once the startup is complete. When the
unit temperature is greater than 32°F (0°C), the heater is deactivated and the unit continues its start-up
sequence.
The effect on device startup time at various temperatures is defined in Table 6.
Table 6: Force 4600C startup times based on ambient temperature
InitialTemperature Startuptime(frompowerontooperational)
-22°F (-30°C) H 20 minutes
-4°F (-20°C) 6 minutes
14°F (-10°C) 2 minutes, 30 seconds
Wind loading
Ensure that the device and the structure on which it is mounted are capable of withstanding the
prevalent wind speeds at a proposed ePMP site. Wind speed statistics are available from national
meteorological offices.
The device and its mounting bracket are capable of withstanding wind speeds of up to 180 kph (124
mph).
Wind blowing on the device will subject the mounting structure to significant lateral force. The
magnitude of the force depends on both wind strength and the surface area of the device. Wind loading
is estimated using the following formulae:
Force (in kilograms) = 0.1045aV
2
Where: Is:
a the surface area in square meters
V wind speed in meters per second
Force (in pounds) = 0.0042Av
2
Where: Is:
A the surface area in square feet
v wind speed in miles per hour
