Cambium Networks PTP 850E User Manual

Chapter 15: Ethernet Services and Interfaces (CLI) Configuring Automatic State Propagation and Link Loss
Forwarding (CLI)
phn-3963_008v000
Page 15-39
o A failure on the remote side of the link is propagated to any of local Ethernet ports 3 or 4 that share an
LLF ID with an Ethernet interface in an ASP pair with the remote radio.
o The trigger delay for Ethernet port 3 is 100 ms. There is no trigger delay for Ethernet port 4.
root> auto-state-propagation add eth-port-to-radio eth-slot 1 eth-port 1
radio-slot 2 radio-port 1 llf-id 1
root> auto-state-propagation add eth-port-to-radio eth-slot 1 eth-port 2
radio-slot 2 radio-port 2 llf-id 2
root> auto-state-propagation configure eth-port eth-slot 1 eth-port 1
asp-admin enable remote-fault-trigger-admin enable csf-mode-admin disable
trigger-delay 100
root> auto-state-propagation configure eth-port eth-slot 1 eth-port 2
asp-admin enable remote-fault-trigger-admin enable csf-mode-admin disable
trigger-delay 5000
root> auto-state-propagation add eth-port-to-radio eth-slot 1 eth-port 3
radio-slot 1 radio-port 2 llf-id 1
root> auto-state-propagation configure eth-port eth-slot 1 eth-port 3
asp-admin enable remote-fault-trigger-admin enable csf-mode-admin disable
