CAME A 3000 User Manual

p.
2
2 -
Manual code:
319S63
319S63 ver.
2.0
2.0 11/2011
© 11/2011 © CAME cancelli automatici s.p.a. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.a. to notify said changes.
ENGLISH
The overall power load of the connected operator must not exceed 320 W.
2.1 Intended use
1 Legend of symbols
2 Intended use and limits to use
The ZF1N control panel is suitable for swing gate operators of the ATI, FERNI, FAST, KRONO series that powered by 230 V.
Any installation and use other than that specified in this manual is forbidden.
3 Reference standards
"IMPORTANT INSTALLATION SAFETY INSTRUCTIONS"
“WARNING: IMPROPER INSTALLATION MAY RESULT IN SERIOUS HARM. PLEASE FOLLOW ALL INSTALLATION INSTRUCTIONS”
“THIS MANUAL IS INTENDED ONLY FOR PROFESSIONAL INSTALLERS OR OTHER COMPETENT INDIVIDUALS”
2.2 Limits to use
Came Cancelli Automatici employs an ISO 9001:14001 certified quality management system and an ISO 14001 environmental
management system. Came entirely engineers and manufactures in Italy.
This product is compliant with: see statement of compliance.
Engineered and built entirely by Came Cancelli Automatici
S.p.A.
Power supply 230 V AC on terminals L1 and L2. The control panel
is protected by a 5 A fuse, while the low voltage accessories (24
V) are protected by a 3.15 A fuse.
Warning! The overall power of the 24 V accessories must not
exceed 20 W.
All connections are protected by quick fuses, see table.
The card provides and controls the following functions:
- automatic closing after an opening command;
- maintained action command.
The available command modes are:
- opening/closing;
- total stop.
The photocells, after detecting an obstacle, may trigger:
- the reopening of the closing gate;
- a total stop.
Specific trimmers regulate:
- the working time for automatic closing;
- the delayed closing time of operator 2;
- the working time.
You can also connect:
- 12 V electro-lock
- gate open warning-lamp.
This symbol shows parts which must be read with care.
This symbol means the parts which describe safety issues.
This symbol tells you what to tell the end-user.
FUSE TABLE
to protect: fuses for:
Electronic board (line)
A 5
Command devices and accessories
(control unit
3.15A
TECHNICAL DATA
Power supply 230 V - 50/60 Hz
Maximum allowed power load 320 W
Power draw when idle
40 mA
maximum power for 24 V accessories 20W
Circuit insulation class
Container material ABS
Container protection rating IP54
Working temperature - 20 / +55°C
4 Description

CAME A 3000 Specifications

General

Brand	CAME
Model	A 3000
Category	Gate Opener
Language	English
