2.0 11/2011
© 11/2011 © CAME cancelli automatici s.p.a. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.a. to notify said changes.
ENGLISH
Warning devices
Gate open warning light Contact rated for: 24 V - 3 W Max.)
Warns of open gate position, turns off when gate is closed.
Safety devices
C1 = (N.C.) contact for reopening while closing
Input for safety devices like photocells, sensitive
edges and other devices that comply with EN 12978
regulations. While the door is closing, opening the
contact will invert movement until it is fully opened.
if unused, short-circuit contact 2-C1.
C1 = (N.C.) contact.) for reopening while closing
Flashing light (contact rated for: 230V AC - 25W Max.) Flashes while
gate opens and closes.
if unused
