K
A
B
Page 16 - Manual FB00801-EN - ver. 1 - 07/2017 - © CAME S.p.A. - The contents of this manual are subject to change at any time without prior notice.
Use the B buttons to set
the desired compensation value.
N.B. The setting is saved in the
permanent device memory.
Set the operating mode to OFF.
Press button P A.
Changing the temperature sensor calibration
If the device is in a position that means that it is dicult for it to detect the correct temperature,
it is possible to modify the temperature detected by ± 3 °C in increments of a tenth of a degree.
Setpoint
Time
Prog.
Cycle length
(minutes)
Minimum ON
time (minutes)
Proportional
band
Type of system
P1 10 1 1.5 °C
Base for gas burner, fan coils, zone
valves, aluminium radiators
P2 5 1 1.5 °C Electric radiators
P3 20 2 1.5 °C Radiant or underfloor systems, cooling
P4 from 5 to 40 from 1 to 5 from 1 °C to 3 °C
Temperature
