24 0 10 11 E
X
+ E -
FC FA F
M N
10 11 E
M
+
+
-
-
p. 16 - Manual FA00000-EN - 02/2018 - © CAME S.p.A. - "Translated original instructions"
Accessories power supply output 24 V AC/DC, max 20 W
Control board power supply 24 V AC/DC
Power supply 230 V AC 50/60 Hz
INPUT VOLTAGE
Flashing light (Contact rating 24 V AC/DC - 25 W max)
Closing limit-switch (NC contact)
Opening limit-switch (NC contact)
CONNECTING THE GEARMOTOR WITH ENCODER AND ENDSTOPS
Green
Brown
White
24 V DC gearmotor
Encoder
SIGNALING DEVICES
