p. 28 - Manual FA01442-EN - 12/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Original instructions
Import/export data
Save user data and system configuration data on a MEMORY ROLL card.
The stored data can be reused for another control board to configure another system in the same way.
Before inserting and removing the MEMORY ROLL card, DISCONNECT THE MAINS POWER SUPPLY TO THE LINE.
1
Insert the MEMORY ROLL card into the corresponding connector on the control board.
2
Press the “Enter” button to access programming.
3
Use the arrows to choose the desired function.
The functions are displayed only when a MEMORY ROLL card is inserted.
- Save data
Save user data, timings and configurations to the memory device (memory roll or USB key).
- Read data
Upload user data, timings and configurations from the memory device (memory roll or USB key).
Once the data have been saved and loaded, remove the MEMORY ROLL card.
