CAME BXV06AGS User Manual

p. 9 - Manual FA01442-EN - 12/2019 - © CAME S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Original instructions
Technical data
MODELS BXV04AGS BXV06AGS BXV08AGS BXV10AGS BXV04RGS BXV06RGS BXV08RGS BXV10RGS
Power supply (V - 50/60 Hz) 230 AC 230 AC 230 AC 230 AC 110 AC 110 AC 110 AC 110 AC
Motor power supply (V) 24 DC 24 DC 24 DC 24 DC 24 DC 24 DC 24 DC 24 DC
Standby consumption (W) 5,5 5.5 5.5 5.5 5.5 5.5 5.5 5.5
Power (W) 170 270 400 400 170 270 400 400
Maximum current draw (mA) 7 11 16 16 7 11 16 16
Colour RAL 7024 RAL 7024 RAL 7024 RAL 7024 RAL 7024 RAL 7024 RAL 7024 RAL 7024
Operating temperature (°C) -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55
Thrust (N) 350 600 800 1000 350 600 800 1000
Maximum operating speed (m/min) 12 12 11 11 12 12 11 11
Operating time (s) 180 180 180 180 180 180 180 180
Duty cycle HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
Protection rating (IP) 44 44 44 44 44 44 44 44
Insulation class IIIIIIII
MODELS BXV06AGM BXV10AGM BXV04ALS BXV06ALS BXV08ALS BXV10ALS
Power supply (V - 50/60 Hz) 230 AC 230 AC 230 AC 230 AC 230 AC 230 AC
Motor power supply (V) 24 DC 24 DC 24 DC 24 DC 24 DC 24 DC
Standby consumption (W) 5.5 5.5 5,5 5.5 5.5 5.5
Power (W) 270 400 170 270 400 400
Maximum current draw (mA) 11 16 7 11 16 16
Colour RAL 7024 RAL 7024 RAL 7040 RAL 7040 RAL 7040 RAL 7040
Operating temperature (°C) -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55
Thrust (N) 600 1000 350 600 800 1000
Maximum operating speed (m/
min)
12 11 12 12 11 11
Operating time (s) 180 180 180 180 180 180
Duty cycle HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
HEAVY-DUTY
SERVICE
Protection rating (IP) 44 44 44 44 44 44
Insulation class I I IIII
Cable types and minimum thicknesses
Cable length (m) up to 20 from 20 to 30
Power supply 230 V AC 3G x 1.5 mm2 3G x 2.5 mm2
24 V AC/DC flashing beacon 2 x 1 mm2 2 x 1 mm2
TX Photocells 2 x 0.5 mm2 2 x 0.5 mm2
RX photocells 4 x 0.5 mm2 4 x 0.5 mm2
Command and control devices * no. x 0.5 mm2 * no. x 0.5 mm2
* no. = see product assembly instructions - Warning: the cable cross-section is indicative and varies according to the motor power and cable length.
When operating at 230 V and outdoors, use H05RN-F cables compliant with 60245 IEC 57 (IEC); when operating indoors, use H05VV-F cables compliant
with 60227 IEC 53 (IEC). For power supplies up to 48 V, you can use FROR 20-22 II cables compliant with EN 50267-2-1 (CEI).
To connect the antenna, use RG58 cable (up to 5 m).
For paired connection and CRP, use UTP CAT5 cable (up to 1,000 m).
If the cable lengths differ from those specified in the table, define the cable cross-sections according to the actual power draw of the connected devices
and in line with regulation CEI EN 60204-1.
For multiple, sequential loads along the same line, recalculate the values in the table according to the actual power draw and distances. For information
on connecting products not covered in this manual, please see the documentation accompanying the products themselves.
