p.
3 - Manual code:
119 U31EN v.
7 -
10/2016 - © Came S.p.A. The contents of this manual may be changed at any time without prior notice.
This symbol shows parts which must be read with care.
This symbol means the parts which describe safety issues.
This symbol tells you what to tell the end-user.
The F7024N gearmotor is engineered and built by CAME S.p.A. to comply with current safety laws and regulations, and
to operate swing-gates in residential or apartment-block settings involving gate-leaves of no more than 300 kg. Any
installation and use other than that specified in this manual is forbidden.
Self-locking gearmotor complete with jointed transmission-arm for gate-leaves up to 2.3 m long.
Power supply to control panel: 230 V AC 50/60Hz
Motor power supply: 24 V DC
Maximum draw: 11A
Power: 140W
Maximum Torque: 180Nm
Opening time (90°): from 16 to 45 s
Duty cycle Intensive use
Protection rating: IP54
Weight: 10.1 kg
Insulation class:
Gate-leaf length 1 m 1.5 m 2 m 2.3 m max
Gate-leaf weight 300 kg max 250 kg 215 kg 200 kg
Opening 110 max
We suggest you always fi t an electrolock onto swing gates for a more reliable closure.
Legend of symbols
Intended use
Destination and conditions of use
Conditions of use
Operator
Description
Technical features
