CAME G4040E User Manual

p.
2
2 - Manual code: FA0 0132
- E N
-EN v.
2
2 08/2016 © CAME Cancelli Automatici S.p.A. -The data and information in this manual may be changed at any time and without notice.
Danger of hand crushing
Danger! High voltage.
No transiting while the barrier is moving
WARNING!
important safety instructions for people:
READ CAREFULLY!
PREMISE
• EMPLOY THIS PRODUCT ONLY FOR THE USE FOR WHICH IT WAS EXPRESSLY MADE.
A
NY OTHER USE IS DANGEROUS. CAME CANCELLI AUTOMATICI S.P.A IS NOT LIABLE
FOR ANY DAMAGE CAUSED BY IMPROPER, WRONGFUL AND UNREASONABLE USE •
T
HE SAFETY OF THIS PRODUCT AND ITS PROPER FITTING DEPENDS, THEREFORE, ON
RESPECTING ITS TECHNICAL CHARACTERISTICS AND PROPER FITTING, TO BE DONE IN
STATE-OF-THE-ART FASHION, AND UNDER SAFE CONDITIONS AS EXPRESSLY EXPLAINED
IN THE LITERATURE THAT COMES WITH THE PRODUCT. • KEEP THESE WARNINGS
TOGETHER WITH THE INSTALLATION AND OPERATION MANUALS THAT COME WITH THE
OPERATOR.
B
EFORE INSTALLING
(CHECKING WHAT'S THERE: IF SOMETHING IS MISSING, DO NOT CONTINUE UNTIL YOU
HAVE COMPLIED WITH ALL SAFETY PROVISIONS)
• FITTING AND TESTING MUST BE BE ONLY PERFORMED BY QUALIFIED TECHNICIANS •
L
AYING THE CABLES, INSTALLATION AND TESTING MUST FOLLOW STATE-OF-THE-ART
PROCEDURES AS DICTATED BY REGULATIONS • BEFORE BEGINNING ANY OPERATION IT
IS MANDATORY TO CAREFULLY READ ALL INSTRUCTIONS; IMPROPER INSTALLATION MAY
RESULT IN SERIOUS HARM TO PEOPLE AND THINGS • MAKE SURE THE BOOM IS IN
GOOD MECHANICAL STATE, BALANCED AND ALIGNED, AND THAT IT OPENS AND CLOSES
PROPERLY. ALSO, IF NEEDED, FIT SUITABLE PROTECTIONS OR USE PROPER SAFETY
SENSORS • IF THE OPERATOR IS TO BE INSTALLED AT A HEIGHT OF OVER 2.5 M FROM
THE GROUND OR OTHER ACCESS LEVEL, MAKE SURE YOU HAVE ANY NECESSARY PRO-
TECTIONS AND/OR WARNINGS IN PLACE • IF ANY PEDESTRIAN OPENINGS ARE FITTED
INTO THE OPERATOR, THERE MUST ALSO BE A A SYSTEM TO BLOCK THEIR OPENING
WHILE THEY ARE MOVING • MAKE SURE THAT THE OPENING AUTOMATIC BARRIER CAN-
NOT ENTRAP PEOPLE AGAINST THE FIXED PARTS OF THE OPERATOR • DO NOT INSTALL
THE OPERATOR UPSIDE DOWN OR ONTO ELEMENTS THAT COULD YIELD AND BEND. IF
NECESSARY, ADD SUITABLE REINFORCEMENTS TO THE ANCHORING POINTS • DO NOT
INSTALL ON TILTED SURFACES • MAKE SURE THE TEMPERATURE RANGE SHOWN ON
THE PRODUCT LITERATURE IS SUITABLE TO THE CLIMATE WHERE IT WILL BE INSTALLED
AS EXPLAINED IN THE MANUAL.
I
NSTALLING
• SUITABLY SECTION OFF AND DEMARCATE THE ENTIRE INSTALLATION SITE TO PRE-
VENT UNAUTHORIZED PERSONS FROM ENTERING THE AREA, ESPECIALLY MINORS AND
CHILDREN • BE CAREFUL WHEN HANDLING OPERATORS THAT WEIGH OVER 20 KG.
I
F NEED BE, USE PROPER SAFETY HOISTING EQUIPMENT • THE CE-MARKED SAFE-
TY DEVICES (PHOTOCELLS, STEPPING PLATES, SENSITIVE SAFETY-EDGES, EMERGENCY
BUTTONS, AND SO ON), MUST BE FITTED IN COMPLIANCE WITH THE REGULATIONS
IN EFFECT AND ACCORDING TO STATE-OF-THE-ART CRITERIA, TAKING INTO ACCOUNT
THE ENVIRONMENT, THE TYPE OF REQUIRED SERVICE AND OF THE WORKING FORCES
APPLIED TO MOVING LEAVES. ANY SHEARING OR CONVEYING POINTS MUST BE SENSOR-
PROTECTED • ANY RESIDUAL RISKS MUST BE POINTED OUT TO END USERS AND
HIGHLIGHTED WITH PICTOGRAMS AS PROVIDED BY THE LAW. • ALL OPENING COM-
MANDS (THAT IS, BUTTONS, KEY SWITCHES, MAGNETIC READERS, AND SO ON) MUST
BE INSTALLED AT LEAST 1.85 M FROM THE PERIMETER OF THE BARRIER'S WORKING
AREA, OR WHERE THEY CANNOT BE REACHED FROM OUTSIDE THE BARRIER. ALSO, ANY
DIRECT COMMANDS (BUTTONS, TOUCH PANELS, AND SO ON) MUST BE INSTALLED AT
LEAST 1.5 M FROM THE GROUND AND MUST NOT BE REACHABLE BY UNAUTHORIZED
PERSONS • THE AUTOMATIC BARRIER MUST VISIBLY SHOW ITS IDENTIFICATION DATA. •
B
EFORE CONNECTING THE MAIN POWER SUPPLY MAKE SURE THAT THE IDENTIFICATION
DATA CORRESPOND TO THE THOSE OF THE NETWORK • THE AUTOMATIC BARRIER MUST
BE CONNECTED TO AN EFFECTIVE REGULATION GROUNDING SYSTEM.
• T
HE MANUFACTURER DECLINES ANY LIABILITY FOR USING NON-ORIGINAL PRODUCTS;
WHICH WOULD RESULT IN WARRANTY LOSS • ALL MAINTAINED ACTION COMMANDS,
MUST BE FITTED IN PLACES FROM WHICH THE MOVING BARRIER AND TRANSIT AND
DRIVING AREAS ARE VISIBLE • APPLY, IF MISSING, A PERMANENT SIGN SHOWING THE
POSITION OF THE RELEASE DEVICE • BEFORE DELIVERING TO THE USERS, MAKE SURE
THE SYSTEM IS EN 12453 AND EN 12445 STANDARD COMPLIANT (REGARDING
IMPACT FORCES), AND ALSO MAKE SURE THE SYSTEM HAS BEEN PROPERLY ADJUSTED
AND THAT ANY SAFETY, PROTECTION AND MANUAL RELEASE DEVICES ARE WORKING
PROPERLY • APPLY WARNING SIGNS WHERE NECESSARY AND IN A VISIBLE PLACE
(
SUCH AS THE GATE'S LICENSE PLATE)
S
PECIAL USER-INSTRUCTIONS AND RECOMMENDATIONS
• KEEP BARRIER OPERATION AREAS CLEAN AND FREE OF ANY OBSTRUCTIONS. MAKE
SURE THE PHOTOCELL'S OPERATING FIELD IS CLEAR OF ANY OBSTRUCTIONS • DO NOT
ALLOW CHILDREN TO PLAY WITH FIXED COMMANDS, OR TO LOITER IN THE BARRIER'S
MANEUVERING AREA. KEEP ANY REMOTE CONTROL TRANSMITTERS OR ANY OTHER
COMMAND DEVICE AWAY FROM CHILDREN, TO PREVENT THE OPERATOR FROM BEING
ACCIDENTALLY ACTIVATED • THE APPARATUS MAY BE USED BY CHILDREN OF EIGHT
YEARS AND ABOVE AND BY PHYSICALLY, MENTALLY AND PERCEPTIVELY CHALLENGED
PEOPLE, OR EVEN ONES WITHOUT ANY EXPERIENCE, PROVIDED THIS HAPPENS UNDER
CLOSE SUPERVISION OR ONCE THEY HAVE BEEN PROPERLY INSTRUCTED TO USE THE
APPARATUS SAFELY AND TO THE POTENTIAL HAZARDS INVOLVED • CHILDREN MUST
NOT PLAY WITH THE APPARATUS. CLEANING AND MAINTENANCE BY USERS MUST NOT
BE DONE BY CHILDREN, UNLESS PROPERLY SUPERVISED • FREQUENTLY CHECK THE
SYSTEM FOR ANY MALFUNCTIONS OR SIGNS OF WEAR AND TEAR OR DAMAGE TO
THE MOVING STRUCTURES, TO THE COMPONENT PARTS, ALL ANCHORING POINTS,
INCLUDING CABLES AND ANY ACCESSIBLE CONNECTIONS • FREQUENTLY CHECK THE
SYSTEM FOR ANY MALFUNCTIONS OR SIGNS OF WEAR AND TEAR OR DAMAGE TO
THE MOVING STRUCTURES, TO THE COMPONENT PARTS, ALL ANCHORING POINTS,
INCLUDING CABLES AND ANY ACCESSIBLE CONNECTIONS. KEEP ANY HINGES, MOVING
JOINTS AND SLIDE RAILS PROPERLY LUBRICATED. PERFORM FUNCTIONAL CHECKS ON
THE PHOTOCELLS AND SENSITIVE SAFETY EDGES, EVERY SIX MONTHS. CONSTANTLY
CLEAN THE PHOTOCELLS' GLASS COVERS USING A SLIGHTLY WATER-MOISTENED CLOTH;
DO NOT USE SOLVENTS OR CHEMICALS THAT COULD DAMAGE THE DEVICES • IF
REPAIRS OR MODIFICATIONS ARE REQUIRED TO THE SYSTEM, RELEASE THE OPERATOR
AND DO NOT USE IT UNTIL SAFETY CONDITIONS HAVE BEEN RESTORED • CUT OFF
THE POWER SUPPLY BEFORE RELEASING THE OPERATOR FOR MANUAL OPENINGS AND
BEFORE ANY OTHER OPERATION, TO PREVENT POTENTIALLY HAZARDOUS SITUATIONS.
R
EAD THE INSTRUCTIONS • IF THE POWER SUPPLY CABLE IS DAMAGED, IT MUST BE
REPLACED BY THE MANUFACTURER OR AUTHORIZED TECHNICAL ASSISTANCE SERVICE,
OR IN ANY CASE, BY SIMILARLY QUALIFIED PERSONS, TO PREVENT ANY RISK • IT IS
FORBIDDEN
FOR USERS TO PERFORM ANY OPERATIONS THAT ARE NOT
EXPRESSLY REQUIRED OF THEM AND WHICH ARE NOT LISTED
IN THE MANUALS. FOR ANY REPAIRS, MODIFICATIONS AND ADJUSTMENTS AND FOR
EXTRA-ORDINARY MAINTENANCE, CALL TECHNICAL ASSISTANCE • LOG THE
JOB AND CHECKS INTO THE PERIODIC MAINTENANCE LOG.
F
URTHER RECOMMENDATIONS FOR ALL
• KEEP AWAY FROM AND DO NOT LOITER NEAR THE BARRIER AND MECHANICAL
MOVING PARTS • DO NOT ENTER THE BARRIER'S AREA OF OPERATION WHEN IT IS
MOVING • DO NOT COUNTER THE OPERATOR'S MOVEMENT AS THIS COULD RESULT
IN DANGEROUS SITUATIONS • ALWAYS PAY SPECIAL ATTENTION TO ANY DANGEROUS
POINTS, WHICH HAVE TO BE LABELED WITH SPECIFIC PICTOGRAMS AND/OR BLACK AND
YELLOW STRIPES • WHEN USING A SELECTOR SWITCH OR A COMMAND IN MAINTAINED
ACTIONS, KEEP CHECKING THAT THERE ARE NO PERSONS WITHIN THE OPERATING RANGE
OF ANY MOVING PARTS, UNTIL THE COMMAND IS RELEASED • THE BARRIER MAY MOVE
AT ANY TIME AND WITHOUT WARNING • ALWAYS CUT OFF THE POWER SUPPLY BEFORE
PERFORMING ANY MAINTENANCE OR CLEANING.
