MAX

p.
3
3 - Manual code:
FA0 0132
- E N
-EN v.
2
2 08/2016
© CAME Cancelli Automatici S.p.A. - The data and information in this manual may be changed at any time and without notice.
LEGEND
This symbol shows which parts to read carefully.
This symbol shows which parts describe safety issues
This symbol shows which parts to tell users about.
DESCRIPTION
Barrier made of varnished galvanized steel or AISI 304 satin finished stainless steel, set up for accessories.
Intended use
The automatic barrier is designed for private and public parking facilities.
Any installation and/or use other than that specified in this manual is forbidden.
Limits to use
Type G4040E - G4040IE
Maximum clearance width of the passage (m) 3.75
Technical data
Type G4040E - G4040IE
Protection rating (IP) 54
Power supply (V - 50/60 Hz) 230 AC
Power supply motor (V) 24 DC
Max draw (A) 15
Power rating (W) 300
Torque (Nm) 200
Opening time a 90° (s) 2 ÷ 6
Duty cycle INTENSIVE USE
Operating temperature (°C) -20 ÷ +55
Reduction ratio (i) 1/202
Insulation class I
Weight (kg) 55
Dimensions (mm)
