Page 27 - Manual FA01383-EN - 04/2021 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
RSE
Configure the function to be performed by the card inserted in the RSE_1 and RSE_2 connectors.
If an RSE card – configured for paired connections – is plugged into the RSE_1 connector, use the RSE_2 connector for remote connection (CRP). In this
case, a CAME KEY cannot be connected.
F49 rE1
rE2
rE1
1 = Paired
3 = CRP/CAME KEY (Default)
4 = Alternate
rE2
3 = CRP/CAME KEY (Default)
5 = I/O - RS485
6 = ModBus
Save data
Save user data, timings and configurations to the memory device (memory roll or USB key).
The function is displayed only when a USB stick is inserted into the USB port or when a memory roll card is inserted into the control board.
F50 Save data OFF (Default)
ON
Read data
Upload user data, timings and configurations from the memory device (memory roll or USB key).
The function is displayed only when a USB stick is inserted into the USB port or when a memory roll card is inserted into the control board.
F51 Read data OFF (Default)
ON
Transferring MASTER-SLAVE parameters
Enable the sharing of parameters programmed on the Master barrier with the Slave barrier.
This only appears if the F49 function is set to Paired or Alternate.
F52 Transferring MASTER-SLAVE
parameters
OFF (Default)
ON
Opening direction
Set the boom opening direction.
F54 Opening direction 0 = To the left (default)
1 = To the right
CRP address
Assign a unique identification code (CRP address) to the control board. It is used where there are multiple operators connected via CRP.
F56 CRP address 1 to 254
Set up maintenance
Set the number of manoeuvres the operator can perform before a maintenance warning signal is generated. The signal consists of the 3 + 3 times rhythmic
flashing of the [Open] warning light every hour. Device connected to the 10-5 output.
F58 Set up maintenance OFF (Default)
1 to 999 (1 = 1000 manoeuvres)
